AUYBUS PROFIBUS ABCC-DPV1 – High-Performance PROFIBUS-DPV1 Interface Module

Manufacturer:AUYBUS

Model:ABCC-DPV1

Module Type:PROFIBUS-DPV1 Interface

Communication Protocol:PROFIBUS-DPV1

Data Rate:9.6 kbps to 12 Mbps

Power Supply:12-30 V DC

Current Consumption:Typically 250 mA @ 24 V DC

Transmission Distance:Up to 1200 meters

Connector Type:9-pin Sub-D connector

Operating Temperature Range:-40°C to +85°C

Weight:Approximately 0.5 kg

Dimensions:85 mm x 90 mm x 65 mm (LxWxH)

    The AUYBUS PROFIBUS ABCC-DPV1 Digital Input Module is a high-performance solution designed for industrial automation environments. With its support for the PROFIBUS DP-V1 communication protocol, this module seamlessly integrates into existing control systems, enhancing data exchange efficiency. Featuring 16 channels of digital inputs, it can accurately capture and transmit signals from sensors and other field devices. The module is equipped with a robust design capable of operating within a wide temperature range (-25°C to +70°C), ensuring reliable performance even in challenging industrial settings. Its compact size (110 x 90 x 65 mm) and lightweight (0.5 kg) make installation easy and flexible, fitting into tight spaces without compromising functionality. Designed for longevity, the module boasts an IP20 protection rating, safeguarding against dust and minor water ingress. Ideal for use in manufacturing, process control, and energy management systems, the AUYBUS PROFIBUS ABCC-DPV1 Digital Input Module delivers dependable and efficient digital input capabilities.
